RIDGID 13 Amp 10 in. Professional Cast Iron Table Saw (R4520)
RIDGID 13A 10" Cast Iron Professional Table Saw
Built for precision and durability, the RIDGID R4520 features a milled and polished cast iron table with steel extensions and a powerful 13 Amp TEFC induction motor with blade brake. With a 30 in. right rip capacity, integrated 4 in. dust port, and push-pedal caster set, it’s ideal for jobsite and shop use.
Key Features:
- Precision Cast Iron Table: Milled and polished surface with steel extensions for flat, accurate cuts
- Powerful Induction Motor: 13 Amp TEFC motor with blade brake to handle dense materials
- Large Rip Capacity: 30 in. right rip and 15 in. left rip for sheet goods and wide stock
- Integrated Dust Collection: 4 in. dust port connects easily for a cleaner workspace
- Mobility and Storage: Push-pedal caster set and onboard storage for fence, guard, and miter gauge
Specifications Table:
| Specification | Details |
|---|---|
| Amperage | 13 A |
| Bench & Stationary Tool Type | Table Saw |
| Blade Location | Centered |
| Color Family | Orange |
| Construction Material | Cast Iron |
| Cord Length | 6 ft |
| Power Source | Corded |
| Cuts Through | Wood |
| Depth Control | Yes |
| Dust Collection Port | 4 in. |
| Horsepower | 3.25 HP |
| Max Cut Depth at 45° | 2.25 in |
| Max Cut Depth at 90° | 3.25 in |
| Maximum Speed | 3450 RPM |
| Table Tilt Left | 45° |
| Table Tilt Right | 0° |
| Portability | Bench |
| Power Tool Features | No Additional Features |
| Product Weight | 267.23 lb |
| Rip Capacity Left | 15 in |
| Rip Capacity Right | 30 in |
| Tools Product Type | Power Tool |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | Lifetime Service Agreement (with registration) |
| Blade Diameter | 10 in |
| Product Depth | 46.3 in |
| Product Height | 37.187 in |
| Product Width | 30.63 in |
| Work Table Height From Floor | 37.5 in |
| Work Table Length | 27 in |
| Work Table Width | 40 in |
| Work Table Surface | 27 in x 40 in |
| Included Accessories | Push stick, blade guard assembly, push-pedal caster set, assembly hardware, 10 in. carbide-tipped blade, die-cast miter gauge, rip fence, operator’s manual |
Frequently Asked Questions (FAQ):
Q: What blade size and arbor does it use?
A: It includes a 10 in. carbide-tipped blade; arbor size is 5/8 in.
Q: What are the max cut depths?
A: Up to 3.25 in. at 90° and 2.25 in. at 45°.
Q: Does it have dust collection?
A: Yes—an integrated 4 in. dust port for connection to shop vacs or collectors.
Q: Is the saw portable?
A: It’s a stationary bench-style saw with a push-pedal caster set for repositioning around the shop.
Q: What warranty is included?
A: Eligible for RIDGID’s Lifetime Service Agreement with registration within 90 days.
A Workhorse with Boutique-Level Finish
The cast iron table is a study in permanence—sleek, milled, and beautifully balanced for confident, whisper-straight cuts. I love the refined fence and steel extensions, which stretch the workspace like a tailored suit. Style it with a crisp outfeed table and matte-black storage to elevate your shop’s aesthetic. This is the kind of tool that anchors a luxury workshop—performance with presence.
Bring precision and power to your shop—add the RIDGID R4520 to your cart today.
